Technical Specifications
• 1/2" 8MP Progressive Scan CMOS Sensor
• Motorized 3x Zoom Optical Lens
• Max. 15 fps @ 3840x2160
• True WDR, 2D & 3D 120dB NR
• Smart Functions
• Smart IR with a maximum range of 100m
• IP67 and IK10 Ingress Protection
• Dual Voltage Input (12 VDC ±25% / 24 VAC ±25%)
• 12 VDC Output
• Transmission up to 500m with RG59 coaxial cable
The HDCVI system seamlessly integrates with traditional analog systems without replacing existing coaxial cable. Its plug-and-play functionality enables full HD video surveillance without the hassle of network setup.
The camera supports 4K HDCVI and CVBS signal outputs simultaneously with two BCN connectors. Multiple outputs simplify setup in situations such as cleaning with an analyzer. It also allows for integration with various devices, including analog matrix displays or monitors.
The camera features a temporary IR LED array to maximize low-light performance over long distances. The intelligent IR function adjusts the intensity of the camera's infrared LED array to compensate for object distance, preventing overexposure as objects approach.
Supporting dual voltage input (12 VDC ±25% / 24 VAC ±25%) and a 12 VDC output (max. 4W), this camera adapts to even the most unstable power supply conditions. Its 4KV illumination rating offers protection to the camera and its structure from the effects of electrical storms.
